4.6.6.4 FUNCTION SELECT: UTILITY: INTERFACE
UTILITY
INTERFACE
Select information to view using the [
←
] [
→
] arrow keys, then press ENTER.
FUNCTION SELECT: UTILITY: INTERFACE:
TX
OVERHEAD
TYPE
TX OVERHEAD TYPE
NONE
Select None, IDR, IBS, DROP & INSERT, AUPC, IBS-309, or ASYNC for TX
overhead type.
Note: Overhead types are selectable only when Custom is selected for modem type in the
Utility: Modem Type menu.
FUNCTION SELECT: UTILITY: INTERFACE:
RX
OVERHEAD
TYPE
RX OVERHEAD TYPE
NONE
Select None, IDR, IBS, DROP & INSERT, AUPC, IBS-309, or ASYNC for TX
overhead type.
Note: Overhead types are selectable only when Custom is selected for modem type in the
Utility: Modem Type menu.
