6 0 1 P R O S E R I E S
X L
5 - 6
FLUKE BIOMEDICAL
05/15/00
23:48
CONTROL#:
PROCEDURE ID:
LOCATION:
DEVICE TYPE:
MANUFACTURER:
SERIAL#:
ECHNICIAN:BIOMED MAN !
601PRO#: 145536
IEC 601-1
CLASS: I TYPE: BF
AP LEADS:3
(RA-B) (RL-BF) (LA-CF)
MAINS VOLTAGE
LI-Earth:
118.5 V
L2-Earth: 0.2 V
LI-L2: 118.6 V
PROT. EARTH RESISTANCE
TEST CURRENT:25A [OHM]
0.001 [0.200]
INSUL RESISTANCE [MOHM]
Ll, L2-CASE Over [ 2]
AP-INSUL RESIST [MOHM]
RL-Case Over [ 2]
LA-Case Over [ 2]
CURRENT CONSUMPTION
0.0 A
EARTH LEAKAGE CUR. [uA]
NORM POL
0 [ 500]
NO L2 1 [ 1000]
REV POL 1 [ 500]
NO L2 1 [ 1000]
ENCL. LEAKAGE CUR. [uA]
NORM POL
0 [ 100]
NO L2 0 [ 500]
NO EARTH 0 [ 500]
REV POL 0 [ 100]
NO L2 0 [ 500]
NO EARTH 1 [ 500]
PATIENT LEAKAGE CUR [uA]
RA-Earth
B
NORM POL 1 [ 100]
NO L2 1 [ 500]
NO EARTH 1 [ 500]
REV POL 1 [ 100]
NO L2 1 [ 500]
NO EARTH 1 [ 500]
PATIENT LEAKAGE CUR [uA]
RL-Earth
BF
NORM POL 1094 [ 100]F
NO L2 1094 [ 500]F
NO EARTH 1094 [ 500]F
REV POL 1094 [ 100]F
NO L2 1094 [ 500]F
NO EARTH 1094 [ 500]F
PATIENT LEAKAGE CUR (uA]
LA-Earth
CF
NORM POL 941 [ 10]F
NO L2 941 [ 50]F
NO EARTH 941 [ 50]F
REV POL 941 [ 10]F
NO L2 941 [ 50]F
NO EARTH 941 [ 50]F
MAINS ON APP. PART (uA]
ISOLATION POL RL
NORMAL 198 [ 5000]
REVERSE 2328 [ 5000]
Norm Pol, Earth, L2
ISOLATION POL
LA
NORMAL 171 [ 50]F
REVERSE 2012 [ 50]F
Norm Pol, Earth, L2
ISOLATION POL RL
NORMAL 199 [ 5000]
REVERSE 2331 [ 5000]
Rev Pol, Earth, L2
ISOLATION POL LA
NORMAL 172 [ 50]F
REVERSE 2013 [ 50]F
Rev Pol, Earth, L2
PATIENT AUX CURRENT (uA]
NORM POL, EARTH, L2
RA-AII 0 [ 100]
RL-AII 0 [ 100]
LA-AII 0 [ 10]
PATIENT AUX CURRENT (uA]
NORM POL, EARTH, NO L2
RA-AII 0 [ 500]
RL-AII 0 [ 500]
LA-AII 0 [ 50]
PATIENT AUX CURRENT (uA]
NORM POL,NO EARTH,L2
RA-AII 0 [ 500]
RL-AII 0 [ 500]
LA-AII 0 [ 50]
PATIENT AUX CURRENT (uA]
REV POL, EARTH, L2
RA-AII 0 [ 100]
RL-AII 0 [ 100]
LA-AII 0 [ 10]
PATIENT AUX CURRENT (uA]
REV POL, EARTH, NO L2
RA-All 0 [ 500]
RL-All 0 [ 500]
LA-All 0 [ 50]
PATIENT AUX CURRENT [uA]
REV POL, NO EARTH, L2
RA-All 0 [ 500]
RL-All 0 [ 500]
LA-All 0 [ 50]
Comments:
UNIT FAILED
