DIMENSIONS
DV-HMSW4K-88
DV PRO - HDMI 8x8 4K MATRIX SWITCHER
IR
POWER
LOCK
INPUT SELECT
OUTPUT SELECT
1T1
ALL
1
2
3
4
5
6
7
8
MENU
SELECT
UP
DOWN
ESC
ENTER
FSR
FSR
1
2
3
4
5
6
7
8
IR INPUT
1
2
3
4
5
6
7
8
IR OUTPUT
1
2
3
4
5
6
7
8
HDMI INPUT
1
2
3
4
5
6
7
8
HDMI OUTPUT
LAN
RS-232
WIRED
IR
CONTROL
IR
12 VDC
DEPTH INSIDE RACK IS APPROXIMATELY 9.25"
17.32 CHASSIS WIDTH
18.34
19.02
1.25
1.74
