MDE-4485 Gasboy Pulser Kits X:1 EQ 25 XXX Installation • June 2005 Page 5
Installing the X:1 EQ 25 XXX Pulser Kit
Installing the X:1 EQ 25 XXX Pulser Kit
Preparation
1 Request permission from the manager/owner to remove power from the unit and then remove
power using normal procedures. Observe the lockout/tagout safety procedures.
2 Make sure you have the proper kit for the model dispenser to be retrofitted.
3 Be prepared to follow all applicable safety rules and procedures.
4 Using the proper tools, remove the covers from the unit. Place covers in a safe place to prevent
damage or scratches. Save the mounting hardware for reuse later.
Replacing the Pulser Meter
1 Using the proper wrench, remove the five mounting bolts (See Figure 1 ) securing the existing
meter in place and remove the meter.
2 Be sure all the existing gasket is removed and the surfaces are clean.
3 In the kit, locate the new meter, the M05617B001 gasket, and the M05613B001 gasket.
4 Position the two gaskets and the meter in place (where the existing meter was removed in step
1) and loosely secure with the five mounting bolts removed from the existing meter.
5 When meter is seated properly in place, tighten the mounting bolts securely.
