MDE-5163A Boot Switch Kit (M14142K001) Installation Instructions · August 2014
Page 9
Installing Boot Switch Kit (M14142K001)
Figure 9: Installing Nozzle Bracket Lock Bushing
Nozzle Bracket Lock
Bushing (M14068B001)
Cotter Pin (K02124)
5
Install the extension spring and secure the lift arm set screw.
Figure 10: Installing Extension Spring
Extension Spring
(064400)
