Preparation (Continued)
Detection & Measurement (Main)
Set up speakers (Audyssey® Setup)
5
Select “Start” and then press
ENTER
.
The subwoofer volume setting screen
is displayed.
Audyssey Setup
Back
Next
Connect the calibration microphone to the SETUP MIC input
on the front the AV receiver.
6
Select “Next” and then press
ENTER
.
Audyssey Setup
Back
Next
VOLUME
MIN
MAX
If your subwoofer has a volume control on it, please set it
at 50%...
NOTE
If “Caution!” is displayed on TV screen:
Go to “Error messages” (
and perform the necessary procedures.
If the problem is resolved, return and restart “Audyssey® Setup”.
Going back to the previous screen
Select “Back” and then press
ENTER
.
When measuring has stopped
q
Press
BACK
to display the popup screen.
w
Press
o
to select “Yes”, and then press
ENTER
.
Setting up the speakers again
Repeat the operation from step 4.
• This step automatically checks the speaker configuration and speaker
size, and calculates the channel level, distance, and crossover
frequency.
It also corrects distortion in the listening area.
7
Select “Begin Test” and then press
ENTER
.
When measuring begins, a test tone is output from each
speaker.
• Measurement requires several minutes.
8
The detected speakers are displayed.
• The illustration below shows an example of when the front
speakers, center speaker, subwoofer and surround speakers have
been detected.
Audyssey Setup
Repeat Last Test
Next
Speaker Detection
Front
Center
Subwoofer
Surround
Surround Back
:Yes
:Yes
:Yes
:Yes
:2spkrs
NOTE
If a connected speaker is not displayed, the speaker may not be
connected correctly. Check the speaker connection.
9
Select “Next” and then press
ENTER
.
Basic v
ersion
A
dv
anced v
ersion
Inf
or
mations
Basic v
ersion
v See overleaf
