26
ENGLISH
1 INPUT SETUP (ASSIGNABLE DIGITAL
INPUT AND COMPONENT VIDEO INPUT)
4 digital inputs and 2 component video inputs can be
assigned to a desired source.
Use this menu to select the digital input jack to be
assigned to the input source.
1. Select “ INPUT SETUP ” in SETUP MAIN
MENU with 3 or 4 cursor button, and press the
ENTER button.
1-1 INPUT SETUP
FUNC:MODE :DIG:HDMI:COMP
------------------------
TV :AUTO : 3 : - : -
DVD :AUTO : 1 : 1 : 1
VCR1:AUTO : - : - : 3
DSS :AUTO : 2 : 2 : 2
AUX1:AUTO : F : - : -
MAIN NEXT EXIT
1-2 INPUT SETUP
FUNC:MODE :DIG:HDMI:COMP
------------------------
CD :AUTO : 4 : :
TAPE:AUTO : - : :
CD-R:AUTO : 5 : :
AUX2:AUTO : - : :
MAIN RETURN EXIT
2. To select the input source and MODE, press
the 3 or 4 cursor buttons.
3. To select “ DIG ” “ HDMI ” or “ COMP ” for the input
jack, press the 1 or 2 cursor buttons.
Select “ DIG ” for input sources, for automatic
detection of the digital input signal condition.
If there is not a digital signal present, but there
is an analog signal present, the analog signal
will be played.
Select “ DIG ”, when only a digital signal will be
used. Select “ ANA ” for input sources for which
no digital input jacks are used.
4. To select the vdieo source, select “ HDMI ” or
“ COMP ” by pressing the 3 or 4 cursor buttons,
and press the 1 or 2 cursor buttons to select
the vdieo source to be assigned .
5. After you complete this portion of the set up,
move the cursor to MAIN with the 3 or 4 cursor
buttons and press the ENTER button.
Notes:
• When TUNER is fi xed to the analog input, you can
not select any digital input.
• When a DTS-LD or DTS-CD is playing, this setup is
not available. This is to avoid noise being generated
from the analog input.
• If “DIG” is selected and a DVD, compact disc or
LD is fast-forwarded during playback, decoded
signals may produce a skipping sound. In such cases,
change the setting to DIGITAL.
2 SPEAKER SETUP
After you have installed the SR4001/SR5001,
connected all the components, and determined the
speaker layout, it is now time to perform the settings
in the Speaker Setup menu for the optimum sound
acoustics for your environment and speaker layout.
Before you perform the following settings, it is
important that you first determine the following
characteristics:
2-1 SPEAKERS SIZE
When setting the speaker size in the SPEAKER
SIZE sub-menu, use the guidelines given below.
LARGE:
The complete frequency range for the channel you
are setting will be output from the speaker.
SMALL:
Frequencies of the channel you are setting lower
than approx. 100 Hz will be output from the
subwoofer.
If the Subwoofer is set to “
NONE ” and the front
speakers are set to “ LARGE ,” then the sound will
be output from both the left and right speakers.
2-1 SPEAKERS SIZE
SUBWOOFER : YES
FRONT L/R : LARGE
CENTER : SMALL
SURROUND L/R : SMALL
SURR.BACK : 2CH
SURR.BACK SIZE : SMALL
LPF/HPF : 100Hz
BASS MIX : BOTH
MAIN NEXT EXIT
1. Select “ SPEAKER SETUP ” in SETUP MAIN
MENU with 3 or 4 cursor button, and press the
ENTER button.
2. To select the each speaker, press the 3 or 4
cursor buttons.
3. To select the setting of each speaker size,
press the 1 or 2 cursor buttons.
4. After you complete this portion of the set up,
move the cursor to “ NEXT ” with the 3 or 4
cursor buttons and then press the ENTER
button to go to the next page.
SUBWOOFER:
YES:
Select when a subwoofer is connected.
NONE:
Select when a subwoofer is not connected.
FRONT L/R
LARGE:
Select if the front speakers are large.
SMALL:
Select if the front speakers are small.
• If “NONE” is selected for the Subwoofer setting,
then this setting is fi xed to “LARGE.”
CENTER
NONE:
Select if no center speaker is connected.
LARGE:
Select if the center speaker is large.
SMALL:
Select if the center speaker is small.
SURROUND L/R
NONE:
Select if no surround left and right speakers are
connected.
LARGE:
Select if the surround left and right speakers are
large.
SMALL:
Select if the surround left and right speakers are
small.
SURR. BACK
NONE:
Select if no surround back left and right speakers
are connected.
2CH:
Select if the surround back left and right speakers
are connected.
1CH:
Select if the one surround back speaker is
connected.
In this case, the audio signal is emitted form the
Surround back L output terminal.
Notes:
• If “NONE” is selected for the Surround L/R setting,
then this setting is fi xed to “NONE.”
• You can use surround back speaker terminals as
multi room speaker terminals when you use no
surround back speaker. (See page 23)
SURR. BACK SIZE
LARGE:
Select if the surround back speaker is large.
SMALL:
Select if the surround back speaker is small.
Note:
If “NONE” is selected for the Surround L/R setting,
then this setting is not available.
LPF/HPF
When you use a subwoofer, you can select the cutoff
frequency for the small speakers used. Select one of
the crossover frequency levels according to the size
of the small speaker connected.
80Hz → 100Hz → 120Hz → 150Hz → 180Hz
Notes:
• If using small front speakers, set a slightly higher
frequency. If using large front speakers, set a slightly
lower frequency.
• If Pure-Direct mode, 7.1CH Input is in use, this
function does not take effect.
BASS MIX
• The bass mix setting is only valid when “ LARGE ”
is set for the front speakers and “ YES ” is set for the
subwoofer during stereo playback .
This setting has effect only during playback of
PCM or analog stereo sources.
• When “ BOTH ” is selected, the low frequencies will
be played through the main L&R, as well as the
sub woofer.
In this playback mode, the low frequency range
expand more uniformly through the room, but
depending on the size and shape of the room,
interference may result in a decrease of the actual
volume of the low frequency range.
• By selecting “ MIX ”, the low frequencies will play
through the main L&R only.
Note:
LFE signals during playback of Dolby Digital or DTS,
will be played through the sub woofer.
