56
TASCAM DA-3000
12 – Specifications
Media and formats
Recording media
SD cards:
512MB–2GB SD supported
4GB–32GB SDHC supported
Media ejection: push-push type
CF cards:
1GB–64GB Type I supported
USB flash drives:
2GB–64GB supported
Recording/playback formats
PCM mode
Fs:
44.1, 48, 88.2, 96, 176.4 and 192 kHz
Bit depth:
16 and 24-bit
Playback:
BWF (.wav extension)
Recording:
BWF and WAV (both .wav extension)
DSD mode
Fs:
2.8224 and 5.6448MHz
Playback and recording: DSDIFF (.dff extension)
DSF (.dsf extension)
Number of channels
2 mono/1 stereo
Inputs and outputs
Analog inputs
Unbalanced
Connectors:
RCA pin jacks
Reference input level:
−10 dBV
Maximum input level: +6 dBV
Input impedance:
22 kΩ or higher
Minimum input level:
−22 dBV
Balanced
Connectors:
XLR-3-31 (1: GND, 2: HOT, 3: COLD)
Reference input level:
+4 dBu or +6 dBu (only when
maximum input level is +15 dBu)
Maximum input level: +24 dBu, +22 dBu, +20 dBu, +18
dBu or +15 dBu (use menu to set)
Input impedance:
10 kΩ or higher
Minimum input level:
−8 dBu or −6 dBu (only when
maximum input level is +15 dBu)
Analog outputs
Unbalanced
Connectors:
RCA pin jacks
Reference output level: −10 dBV
Maximum output level: +6 dBV
Output impedance:
200 Ω or less
Balanced
Connector:
XLR-3-32 (1: GND, 2: HOT, 3: COLD)
Reference output level: +4 dBu or +6 dBu (only when
maximum input level is +15 dBu)
Maximum output level: +24 dBu, +22 dBu, +20 dBu, +18
dBu or +15 dBu (set in menu)
Output impedance:
100 Ω or less
PHONES jack
Connector:
6.3mm (1/4") standard stereo jack
Maximum output:
45 mW + 45 mW (32Ω load, 0.1%
distortion)
Digital input
S/PDIF / CASCADE (unbalanced)
Connector:
RCA pin jack
Format:
IEC60958-3 (S/PDIF)
Input frequency:
44.1, 48, 88.2, 96, 176.4 or 192 kHz
(when SRC OFF)
32 kHz–216 kHz (when SRC ON)
Allowable frequency deviation: ±100 ppm (when SRC OFF)
AES/EBU (balanced)
Connector:
XLR-3-31 (1: GND, 2: HOT, 3: COLD)
Format:
AES3-2003/IEC60958-4 (AES/EBU)
Input frequency:
44.1, 48, 88.2, 96, 176.4 and 192 kHz
(when SRC OFF)
32–216 kHz (when SRC ON)
Allowable frequency deviation: ±100 ppm (when SRC OFF)
SDIF-3 (unbalanced)
Connectors:
BNC connector × 2 (L, R)
Format:
SONY SDIF-3/DSD-raw
Clock sync frequency: 44.1 kHz (when 2.8 MHz or 5.6 MHz)
Digital output
S/PDIF / CASCADE (unbalanced)
Connector:
RCA pin jack
Format:
IEC60958-3 (S/PDIF)
AES/EBU (balanced)
Connector:
XLR-3-32 (1: GND, 2: HOT, 3: COLD)
Format:
AES3-2003/IEC60958-4 (AES/EBU)
SDIF-3 (unbalanced)
Connectors:
BNC connector × 2 (L, R)
Format:
SONY SDIF-3/DSD-raw
Clock sync frequency: 44.1 kHz (when 2.8 MHz or 5.6 MHz)
Other connectors
WORD SYNC IN jack
Connector:
BNC
Input level:
equivalent to 5V TTL
Input impedance:
75 Ω ±10%
(includes terminal on/off switch)
Input frequency:
44.1, 48, 88.2, 96, 176.4 or 192 kHz
Allowable frequency deviation: ±100 ppm
WORD SYNC THRU/OUT
Connector:
BNC
Output level:
equivalent to 5V TTL
Output impedance:
75 Ω ±10%
Output frequency:
44.1, 48, 88.2, 96, 176.4 or 192 kHz
(includes THRU/OUT on/off switch)
Frequency stability:
±1 ppm or less (Ta=25ºC)
USB (DEVICE)
Connector:
USB A-type 4-pin
Protocol:
USB 2.0 HIGH SPEED (480 Mbps)
Power supply rating:
DC 5.0V 0.5A
USB (KEYBOARD)
Connector:
USB A-type 4-pin
Protocol:
USB 1.1 FULL SPEED (12 Mbps)
Power supply rating:
DC 5.0V 0.2A
