Basic Management Configuration Chapter 2 Dashboard
2-1
Chapter 2 Dashboard
The dashboard includes four parts; system info, managed access point, device info
and the support info.
2.1 System Info
The system info for the wireless AC is as below:
The information in the figure is:
Name: the name of AC
IP address: the URL address of accessing the AC is 192.168.1.1
MAC address: the mac address of AC is 00-03-0f-11-20-50
System uptime: the normal running time: 1day, 4 hours and 2 minutes
Maximum managed APs: 16
S/N: 111111
Version: 7.0.3.5 (R0035.0088)
: click this icon to refresh the current module.
2.2 Managed Access Point
The managed access point shows the AP information including the MAC address,
location, IP address, profile, software version, status, configuration status and age of AP.
