"JOB FUNCTIONS" - F2 GUIDANCE MODE
16.2
F2
Guidance mode
Selecting guidance mode:
1
2
Fig. 343
1 In the guidance screen, press
Func
.
2 Press
F2
to enable the function.
3 Select a guidance mode (Fig. 344): press
F4
and
F6
to move across the available items
(
A
- Straight guidance mode
,
B
- Curved guidance mode
,
C
- Pivot mode
or
D
- Free guidance mode
)
4 Confirm selection.
3
3
A
C
B
D
4
Fig. 344
A - STRAIGHT GUIDANCE MODE
B - CURVED GUIDANCE MODE
Fig. 345
Fig. 346
Fig. 347
The tracks appearing on the display, which will act as a
guidance reference, are perfectly straight and parallel to the
reference line joining point
A
to point
B
as previously marked.
Upon creation of the reference track, any bends in the
trajectory between
A
and
B
will be ignored.
The tracks appearing on the display, which will act as a guidance reference, include portions that
are not straight, but do not include sharp bends (Fig. 347).
The trajectory between
A
and
B
will be saved and Bravo 400S will create evenly distributed tracks.
C - PIVOT MODE
D - FREE GUIDANCE MODE
Fig. 348
Fig. 349
Specific mode for spraying of field with movable pivots.
The circular trajectory between
A
and
B
will be memorized
and Bravo 400S will create concentric, evenly distributed
tracks.
No guidance references are shown on the display.
The operator will drive freely and will be able to check the
spraying range on the display in real time.
Par.
Exit the function or
data change
Confirm access
or data change
Scroll
(LEFT / RIGHT)
Delete
selected
character
Increase /
decrease
value
Scroll
(UP / DOWN)
Enter
selected
character
