54
ADVANCED SETUP "USER"
10.3.4 Steering warning
Fig. 195
It allows to enable/disable the acoustic signal when the operator must steer in order to align the machine
with the following track, avoiding unsprayed or overlapping areas between the two sprays
(
Steering radius set in par 10.1.12 Working parameters).
Signal enabled
Signal disabled
GUIDANCE
10.3.5 Offset tolerance
Fig. 196 Fig. 197
The guidance screen displays a LED bar
according to the offset with respect to the
reference line.
Each LED indicates an offset value
corresponding to the one set in item
Offset
tolerance (for ex.: 30 cm).
PREFERENCES
10.3.6 Selective job loading
Fig. 198
Fig. 199
It allows enabling/disabling the Loading options
screen (Fig. 199) when the operator loads a previously
saved job (par. 14.5 F5 Resume job).
Screen enabled
Screen disabled
Par.
7.4
Exit the function or
data change Confirm access
or data change Scroll
(LEFT / RIGHT)
Delete
selected
character Increase /
decrease
value
Scroll
(UP / DOWN)
Enter
selected
character
