Enter machine zero offset

The following steps enter the offset count value from machine zero to
the standard’s zero.

To enter the machine zero offset:

U

Highlight the MZ Offset field of the channel being configured

U

Position the Channel’s probe at the standard’s zero reference

U

Press the TEACH soft key

U

Press the ENTER key to enter the machine zero offset

Clear all
Datums

Cycle Power &
Set Machine 0

Clear Old
Values &
Disable SLEC

Enter
Machine 0
Offset

Enter New
Station
Values

Enable SLEC
