Data reports
Report type Screen User actions
Current dimensions (Numeric display) DRO U Press PRINT key
Graphs of dimension values
(SPC subgroups = 1) Graph... U Press PRINT key
Histograms of dimension values
(SPC subgroups = 1) Histo... U Press PRINT key
x chart of subgroup mean values
(SPC subgroups> 1) x chart U Press PRINT key
r chart of subgroup range values
(SPC subgroups>1) r chart U Press PRINT key
Current dimension values (Bar display) Bar... U Press PRINT key
Current dimension values (Dial display) Dial... U Press PRINT key
Data table multiple-dimensions Data... U Press PRINT key
U Respond to prompt
Data table single-dimensions Data... U Press DIMENSION soft key
U Press PRINT key
U Respond to prompt
