566 Manual Operation and Setup
14.5 Using the 3-D T
o
uc
h Pr
obe
14.5 Using the 3-D Touch Probe
Overview
The following touch probe cycles are available in the Manual Operation
mode:
Note that HEIDENHAIN generally does not accept liability
for the function of the touch probe cycles unless you use
HEIDENHAIN touch probes!
Function Soft key Page
Calibrating the effective length Page 571
Calibrating the effective radius Page 572
Measuring a basic rotation using a line Page 576
Setting the datum in any axis Page 580
Setting a corner as datum Page 581
Setting a circle center as datum Page 582
Setting a center line as datum Page 583
Measuring a basic rotation using two
holes/cylindrical studs Page 584
Setting the datum using four
holes/cylindrical studs Page 584
Setting a circle center using three
holes/cylindrical studs Page 584
