Yaskawa Sigma-II Large Capacity - Manual (Page 37)

■ ■ ■ ■ Digital Operator
Σ-Ⅱ Ⅱ Ⅱ Ⅱ Σ-Ⅴ Ⅴ Ⅴ Ⅴ
Digital operator JUSP-OP02A-2 JUSP-OP05A-1-E
JUSP-OP02A-1
Cable for digital operator (for JUSP-OP02A-1) JZSP-CMS00-1
JZSP-CMS00-2
JZSP-CMS00-3
■ ■ ■ ■ Noise Filter
AC100V
Σ-Ⅱ Ⅱ Ⅱ Ⅱ Σ-Ⅴ Ⅴ Ⅴ Ⅴ
30W FN2070-6/07 － － － －
50W/R70F FN2070-6/07 FN2070-6/07
100W/R90F FN2070-6/07 FN2070-6/07
200W/2R1F FN2070-10/07 FN2070-10/07
400W/2R8F － FN2070-16/07
AC200V
Σ-Ⅱ Ⅱ Ⅱ Ⅱ Σ-Ⅴ Ⅴ Ⅴ Ⅴ
30W FN2070-6/07 － － － －
50W/R70A FN2070-6/07 FN258L-7/07
100W/R90A FN2070-6/07 FN258L-7/07
200W/1R6A FN2070-6/07 FN258L-7/07
400W/2R8A FN2070-10/07 FN258L-7/07
0.5kW/3R8A FN258L-7/07 FN258L-7/07
750W/5R5A FN258L-16/07 FN258L-16/07
1.0kW/7R6A FN258L-16/07 FN258L-16/07
1.5kW/120A FN258L-16/07 HF3020C-UQC
2.0kW/180A FN258L-16/07 HF3020C-UQC
3.0kW/200A FN258L-30/07 HF3030C-UQC
5.0kW/330A FMAC-0934-5010 HF3050C-UQC
AC400V
Σ-Ⅱ Ⅱ Ⅱ Ⅱ Σ-Ⅴ Ⅴ Ⅴ Ⅴ
0.5kW/1R9D FN258L-7/07 FN258L-7/07
1.0kW/3R5D FN258L-7/07 FN258L-7/07
1.5kW/5R4D FN258L-7/07 FN258L-7/07
2.0kW/8R4D FN258L-16/07 FN258L-16/07
3.0kW/120D FN258L-16/07 FN258L-16/07
5.0kW/170D FS5559-35-33 FMAC-0934-5010
Name
Type
－ － － －
Name
Servo
Capacity/Current
Display
Type
Type
Noise filter
Name
Servo
Capacity/Current
Display
Type
Noise filter
Noise filter
Name
Servo
Capacity/Current
Display
