Page 23
Model
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
4A0590
<1>
R/L1, S/L2, T/L3
3/0 × 4
3/0 to 300
M12
32.0 to 40.0
(283 to 354)
U/T1, V/T2, W/T3
3/0 × 4
–, +1
–
+3
–
–
<1> Drive models 4A0034 to 4A0590 require the use of closed-loop crimp terminals for UL/cUL compliance. Use only the tools recommended by the
terminal manufacturer for crimping.
Closed-Loop Crimp Terminal Recommendations
Yaskawa recommends using closed-loop crimp terminals on all drive models. UL approval requires the use of UL Listed crimp
terminals when wiring the drive main circuit terminals on models CIMR-Zo2A0031 to 2A0396 and 4A0034 to 4A0590. Use
only crimping tools as specified by the crimp terminal manufacturer. Yaskawa recommends crimp terminals made by JST and
Tokyo DIP (or equivalent) for the insulation cap.
matches the wire gauges and terminal screw sizes with Yaskawa-recommended crimp terminals, tools, and insulation
caps. Refer to the appropriate Wire Gauge and Torque Specifications table for the wire gauge and screw size for your drive
model. Place orders with a Yaskawa representative or the Yaskawa sales department.
The closed-loop crimp terminal sizes and values listed in
are Yaskawa recommendations. Refer to local codes for
proper selections.
Table i.6 Closed-Loop Crimp Terminal Size
Wire Gauge
Terminal
Screws
Crimp Terminal
Model Number
Tool
Insulation
Cap
Model No.
Code
<1>
Machine No.
Die Jaw
2 mm
2
14 AWG
M4
R2-4
YA-4
AD-900
TP-003
100-054-028
3.5 / 5.5 mm
2
12 / 10 AWG
M4
5.5-4NS
YA-4
AD-900
TP-005
100-064-248
8 mm
2
8 AWG
M4
8-4NS
YA-4
AD-901
TP-008
100-064-249
M5
R8-5
YA-4
AD-901
TP-008
100-054-032
14 mm
2
6 AWG
M5
R14-5
YA-4
AD-902
TP-014
100-054-034
M8
R14-8
YA-5
AD-952
TP-014
100-054-035
22 mm
2
4 AWG
M5
22-5NS
YA-5
AD-953
TP-022
100-051-262
M8
R22-8
YA-5
AD-953
TP-022
100-051-263
30 / 38 mm
2
3 / 2 AWG
M8
R38-8
YA-5
AD-954
TP-038
100-051-264
50 / 60 mm
2
1 AWG
1/0 AWG
1/0 AWG × 2P
M8
R60-8
YA-5
AD-955
TP-060
100-051-265
70 mm
2
2/0 AWG
2/0 AWG × 2P
M8
CB70-S8
YF-1 YET-300-1
TD-322,TD-311
TP-080
100-064-417
70-8
100-064-250
M10
70-10
YF-1 YET-300-1
TD-322,TD-311
TP-080
100-064-251
80 mm
2
3/0 AWG × 2P
3/0 AWG × 4P
M10
80-10
YF-1 YET-300-1
TD-323,TD-312
TP-080
100-051-267
M12
80-L12
YF-1 YET-300-1
TD-323,TD-312
TP-080
100-051-558
100 mm
2
4/0 AWG × 2P
4/0 AWG × 4P
M12
100-L12
YF-1 YET-300-1
TD-324,TD-312
TP-100
100-051-560
150 mm
2
250 kcmil × 2P
300 kcmil × 2P
M12
150-L12
YF-1 YET-300-1
TD-325,TD-313
TP-150
100-051-562
<1> Codes refer to a set of three crimp terminals and three insulation caps. Prepare input and output wiring using two sets for each connection.
Example 1: Models with 300 kcmil for both input and output require one set for input terminals and one set for output terminals, so the user should
order two sets of [100-051-272].
Example 2: Models with 4/0 AWG × 2P for both input and output require two sets for input terminals and two sets for output terminals, so the user
should order four sets of [100-051-560].
Note:
Use crimp insulated terminals or insulated shrink tubing for wiring connections. Wires should have a continuous maximum allowable
temperature of 75 °C 600 Vac UL-approved vinyl-sheathed insulation.
i.3 Electrical Installation Safety
YASKAWA ELECTRIC TOEP YAIZ1U 01A YASKAWA AC Drive – Z1000 Safety Precautions
23
