ICA-3150
Appendix B: Bandwidth and Video Size
Estimation
The frame rate of video transmitted from the device depends on connection bandwidth
between client and server, video resolution, codec type, and quality setting of server. Here is a
guideline to help you roughly estimate the bandwidth requirements from your device.
The required bandwidth depends on content of video source. The slow motion video will
produce smaller bit rate generally and fast motion will produce higher bit rate. Actual results
generated by the device may be varying
Resolution
Average range of
data sizes for JPEG
mode
Average bit rate for
MPEG4 mode
Average bit rate for
H.264 mode
320 x 240 8 ~ 20k byte per
frame
256kbps~768kbps
@ 30fps
192kbps~512kbps
@ 30fps
640 x 480 20 ~ 50K byte per
frame
512kbps~3072kbps @
30fps
384kbps~1536kbps
@ 30fps
1920 x 1080 200 ~ 500k byte per
frame
- 1536kbps~10000kbps
@ 30fps
2048 x 1536 300 ~ 750k byte per
frame
- 2048kbps~12000kbps
@ 30fps
Audio streaming also takes bandwidth around 32kbps. Some xDSL/Cable
modem upload speeds could not even reach up to 128 kbps. Thus, you
may not be able to receive good quality video while also streaming audio on
a 128 kbps or lower connection. Even though the upload speed is more
than 128kbps for optimal video performance, disabling audio streaming will
get better video performance.
- 39 -
720P IR Bullet PoE IP Camera
