User’s Manual of WNRT-627
-15-
Distance Outdoor up to 300m (it is limited to the environment)
Channel
America/ FCC: 2.414~2.462GHz (11 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Japan/ TELEC: 2.412~2.484GHz (14 Channels)
RF Power
High: 18 dBm (max)
Middle: 15 dBm
Low: 12 dBm
Receive Sensitivity
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Wireless Management Features
Wireless Operation
Mode
AP, WDS (AP+Bridge)
WEP (64/128/152-bit) encryption security
Encryption Security
WPA-PSK / WPA2-PSK (TKIP/AES)
WPA / WPA2 (TKIP/AES)
WPA / WPA2 enterprise mode (802.1x authentication)
Provides Wireless LAN ACL (Access Control List) filtering
Wireless MAC address filtering
Supports WPS(WIFI Protected Setup )
Wireless Security
Enable/Disable SSID Broadcast
Supports 802.11e WMM (Wi-Fi Multimedia)
Supports Wireless Roaming Wireless Advanced
Provides Wireless Statistics
Router Features
Internet Connection
Type
Shares data and Internet access for users, supporting the following internet accesses:
PPPoE / Russia PPPoE
Dynamic IP
Static IP
Telstra Big Pond
PPTP / Russia PPTP
L2TP / Russia L2TP
NAT firewall with SPI (Stateful Packet Inspection)
NAT with ALG (Application Layer Gateway)
Built-in NAT server supporting Virtual Server, and DMZ
Built-in firewall with IP address filtering, Domain Name filtering, and MAC address filtering
Firewall
Supports ICMP-FLOOD, UDP-FLOOD, TCP-SYN-FLOOD filter, DoS protection
