56
3-1. When you think a malfunction has occurred
SIENNA AAS_U (OM45460U)
Turn the bolt with yellow marking
clockwise using the combination
wrench, and slide the seat until
the marks are aligned as shown
in the illustration.
If you are unable to slide the seat
until the marks are aligned
because the right edge of the
seat cushion interferes with the
sliding door, carry out
and
and slide the seat
until the marks are aligned as
shown in the illustration.
Use the combination wrench to
loosen the two bolts, then slide
the motor out of the way and dis-
connect it from the gear.
Rotate the seat into a position
which does not cause the left
edge of the seat cushion to make
contact with the vehicle body.
STEP
12
STEP
13
STEP
14
STEP
13
STEP
14
