742
6-1. Specifications
Brakes
*
1
: Minimum pedal clearance when depressed with a force of 110 lbf (490 N,
50 kgf) while the engine is running
*
2
: Parking brake pedal travel when depressed with a force of 67.4 lbf (300 N,
30.6 kgf)
Chassis lubrication (AWD models)
Steering
Pedal clearance
*
1
2.99 in. (76 mm)
Pedal free play
0.04
⎯ 0.24 in. (1 ⎯ 6 mm)
Brake pad wear limit
0.04 in. (1.0 mm)
Parking brake lining wear limit
0.04 in. (1.0 mm)
Parking brake pedal travel
*
2
3
⎯ 6 clicks
Fluid type
SAE J1703 or FMVSS No.116 DOT 3
Propeller shafts
Spider
Slide yoke
Lithium base chassis grease, NLGI No.2
Molybdenum-disulfide lithium base chassis
grease, NLGI No.2 or lithium base chassis
grease, NLGI No.2
Free play
Less than 1.2 in. (30 mm)
