Solar Energy Set SES P4033 V3 GB
8
Frequently asked questions
Question: What type of batteries can be used with the kit?
Answer: Any 12 V/33 Ah battery that is used for cars, boats,
motor cycles, etc.
Question: Will the solar panels over-charge my battery?
Answer: The charge regulator ensures that a steady charge
is supplied to the battery and will not be over-charged.
Question: Can I extend/lengthen the battery lead?
Answer: If the lead is extended this can result in a loss of voltage
and insuffi cient power transferred from the solar panels to charge
the battery.
Question: How do I clean the solar panels?
Answer: Dust & dirt should fi rst be swept off the panel surface
using a soft brush then using a wet cloth to wipe the panel surface
to remove remaining dirt & grime. It is recommended that any bird
droppings be removed as soon as possible as if left can cause
damage to the surface.
Question: Is the solar panel kit water proof?
Answer: It is recommended that the kit is not exposed to exces-
sive water as all components apart from the solar panel are not
water proof.
Maintenance
● Very little maintenance is required to keep the inverter and
charge regulator operating properly. Clean the housing periodi-
cally with a damp cloth to prevent accumulation of dust and
dirt.
● The surface of the solar panel should be kept clean by periodi-
cally wiping it with a soft cloth to ensure best performance.
● During long-term storage without being charged, the battery
must be completely recharged every 4-6 months in order to
preserve complete and proper performance.
Technical Data
SOLAR PANEL
Cell type: Mono-Crystalline
Output power Pmax: 40 Wp (2x 20 Wp)
Upm: 17.2 V
Dimension: (592 x 641 x 25) mm open
(296 x 641 x 50) mm folded
SOLAR CHARGE REGULATOR
Max. solar input current: 10 A
Max. load current: 10 A
Over-discharge protection: 11 ± 0.3 V
Over-charge protection:
14.0 – 14.5 V
USB output socket 5 V DC, 500 mA
Ambient humidity: ≤ 80%
Operating temperature: -10°C up to +42°C
Fuse: 10 A
POWER INVERTER
Output power (continuous): 150 W
Output power (peak):
300 W
Stand-by current: ≤ 0.3 A
Target input voltage (DC): 12 V (11 V - 15 V)
Target output voltage (AC): 230 V AC, 50 Hz
Frequency:
50 Hz
USB port: 5 V DC, 500 mA
Output waveform: modifi ed sine wave
Safety
Low battery voltage alarm: 10.5 ± 0.5 V
Low battery voltage cutout: 10.0 ± 0.5 V
Thermal protection:
65 °C
Overload: shutoff
Fuse: 20 A
BATTERY (not included)
Recommended:
12 V/33 Ah; seal lead acid,
deep cycle, long life
(art. no. 1292990)
Note: Power & Current outputs are calculated at maximum and
will vary depending on operating conditions, environments, battery
condition, etc.
Disposal
Dispose of electronic devices in an eco-friendly fashion!
Electronic devices do not belong in your household waste.
Compliant with European Guideline 2002/96/EG for electric
and electronic devices, used electronic devices must be collected
separately and taken in for environmentally sound recycling.
Options for disposing of used devices may be obtained from your
township, city or municipal government.
Incorrect disposal of batteries and rechargeable batteries
can harm the environment! Batteries and rechargeable
batteries do not belong in the household waste. They can
contain poisonous heavy metals and are subject to treatment as
hazardous wastes. Take your used batteries to a municipal collec-
tion site.
Manufacturer
Hugo Brennenstuhl GmbH & Co. KG
Seestraße 1-3 • 72074 Tübingen • Germany
H. Brennenstuhl S.A.S. • F-67460 Souffelweyersheim
lectra-t ag • Blegistrasse 13 • CH-6340 Baar
For further information please see the Service/FAQ section of our
website www.brennenstuhl.com
