HDCVI Standalone DVR User’s Manual
182
Parameter Function
Light and
wiper
You can turn on or turn off the light/wiper.
Figure 5-11
5.6 Image/Relay-out
Select one monitor channel video and then click Image button in section 8, the interface is
shown as Figure 5-12.
5.6.1 Image
Here you can adjust its brightness, contrast, hue and saturation. (Current channel border
becomes green).
Or you can click Reset button to restore system default setup.
Figure 5-12
5.6.2 Relay output
Here you can enable or disable the alarm signal of the corresponding port. See Figure
5-13.
You can click this icon to
display or hide the PTZ
control platform.
3D Intelligent Positioning
Key
