BIOS Setup
Hardware Health Configuration
This section is used to configure the hardware monitor function.
Lowest Speed Value
Min=0
Max=100
Please input Dec number:
BIOS SETUP UTILITY
v02.67 (C)Copyright 1985-2009, American Megatrends, Inc.
← → Select Screen
↑↓ Select Item
Enter Update
F1 General Help
F10 Save and Exit
ESC Exit
Hardware Health Configuration
H/W Health Function
CPU Temperature
System Temperature
Temperature Sensor #3
CPUFAN Speed
SystemFAN Speed
FAN3 Speed
Vcore
5V
+12V
V_DIMM
5VSB
3.3V
VBAT
CPU FAN Mode Setting-Smart FAN
Highest CPU Temperature Limit
2nd CPU Temperature Limit
3rd CPU Temperature Limit
Lowest CPU Temperature Limit
CPU Fan Highest Setting
CPU Fan Second Setting
CPU Fan Third Setting
CPU Fan Fourth Setting
CPU Fan Lowest Setting
Advanced
[Enabled]
:30 o C
:29 o C
:32 o C
:1594 RPM
:N/A
:N/A
:1.144 V
:5.056 V
:12.056V
:1.504 V
:5.017V
:3.376V
:3.312V
[Auto Mode]
[060]
[050]
[040]
[030]
[100]
[075]
[050]
[040]
[030]
H/W Health Function
Enables or disables the hardware monitoring function.
CPU Temperature to VBAT
These fields will show the temperature, fan speed and output voltage of the
monitored devices or components.
CPU Fan Mode Setting-Smart Fan
Selects the fan configuration mode. The options are Auto Mode and Manual
Mode.
Highest CPU Temperature Limit to Lowest CPU Temperature Limit
Sets the CPU’s highest, 2nd, 3rd and lowest temperature limit.
CPU Fan Highest Setting to CPU Fan Lowest Setting
Sets the CPU fan’s highest, 2nd, 3rd, 4th and lowest fan speed value.


