BIOS Setup
PCIPnP
The PCIPnP menu is used to configure PCI Plug and Play devices.
Important:
Setting incorrect field values may cause the system to malfunction.
Clear NVRAM during
System Boot.
BIOS SETUP UTILITY
Exit Chipset
v02.67 (C)Copyright 1985-2009, American Megatrends, Inc.
← → Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Advanced PCI/PnP Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
Clear NVRAM
Plug & Play O/S
PCI Latency Timer
IRQ3
IRQ4
IRQ5
IRQ7
IRQ9
IRQ10
IRQ11
IRQ14
IRQ15
Boot Security Main Advanced PCIPnP
[No]
[No]
[64]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
Clear NVRAM
This field allows clearing the NVRAM during system boot.
Plug & Play O/S
Yes
The operating system onfigures Plug and Play (PnP) devices that are not re-
quired to boot in a Plug and Play supported operating system.
No
The BIOS configures all the devices in the system.
PCI Latency Timer
This feature is used to select the length of time each PCI device will control the
bus before another takes over. The larger the value, the longer the PCI device
can retain control of the bus. Since each access to the bus comes with an initial
delay before any transaction can be made, low values for the PCI Latency Timer
will reduce the effectiveness of the PCI bandwidth while higher values will im-
prove it.
