BIOS Setup
South Bridge Configuration
Enable/Disable USB
controller in system.
BIOS SETUP UTILITY
v02.67 (C)Copyright 1985-2009, American Megatrends, Inc.
← → Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
South Bridge Chipset Configuration
USB Function [Enabled]
EHCI Controller#1 [Enabled]
EHCI Controller#2 [Enabled]
GbE Controller [Enabled]
GbE LAN Boot [Disabled]
GbE Wake Up From S5 [Disabled]
HDA Controller [Enabled]
After G3 [Power On]
PCIE Ports Configuration
On Board LAN2 [Auto]
On Board LAN3 [Auto]
On Board LAN4 [Auto]
Chipset
USB Function
Enables or disables the USB controller.
EHCI Controller#1 and EHCI Controller#2
This field is used to enable or disable the Enhanced Host Controller Interface
(USB 2.0).
GbE Controller
Enables or disables the Gigabit LAN controller.
GbE LAN Boot
Enable this field if you want to use the boot ROM (instead of a disk drive) to
boot-up the system and access the local area network directly. If you want to
change the boot ROM’s settings, type the <Shift> and <F10> keys simultaneous-
ly when prompted during boot-up. Take note: you will be able to access the boot
ROM’s program (by typing <Shift> + <F10>) only when this field is enabled.
GbE Wake Up From S5
When enabled, it allows the network LAN to wake up the system from S5.
HDA Controller
Enables or disables the High Definition Audio controller.
