Digi-Star Model EZ3200/EZ3200V/EZ3200V RC
1. About the product
1
! copyright - 10/24/2001
1. About the product
FEATURES OF MODELS EZ3200, EZ3200V AND EZ3200V RC
"
Three recipe programming modes
- Ingredient percentage of total
- Amount per animal
- Amount per ingredient
"
Accumulation for tracking ingredient usage
"
200 Recipe memory locations
"
99 Programmable ingredient names to simplify loading & unloading
"
Ingredients can be entered in any order
"
Scrolling Help messages for easy recipe programming & operation
"
Front panel calibration without simulator or weights
"
[Select] and [Function] keys to simplify appearance and allow for future expansion
"
A Hold feature to hold the weight stable while moving the scale system
"
Large 1.7" display for greater readability (1" for Model 3200)
"
Fiber-optic back lighting for extremely long life
"
Expanded self diagnostic test capability
"
New powerful microprocessor and expanded memory
OPERATING SPECIFICATIONS
"
Temperature range:
-28
#C to 60#C (-20#F to 140#F)
"
Power requirements:
10.2Vdc - 16Vdc
"
Power on:
160mA, 4L.C. 350
$
"
Power off:
1mA
HOUSING
"
Size (l×h×w):
10.3" × 7.2" × 5.0" (262 × 183 × 127 mm)
"
Weight (unpacked):
4.5 lbs (2.04kg)
"
Display EZ3200:
6-digit alpha numeric LCD, fiberoptic back lighting
Display height EZ3200 = 1" (25.4 mm)
Display height EZ3200V and 3200V RC = 1.7" (43.2 mm)
"
Environmental enclosure: IP65, IEC529
"
Connectors:
AMP, gold plated contacts
