Chapter 6 Specifications RIGOL
DSG3000 User’s Guide 6-1
Chapter 6 Specifications
This chapter describes the specifications of RF signal generator. Specifications are
valid under the following conditions: the instrument in the calibration cycle is stored
at least two hours at 0°C to 50°C temperature, and 40 minutes warm up. The
specifications include measurement uncertainty. Data represented in this manual are
specifications unless otherwise noted.
Typical (typ.): describes characteristic performance, which 80 percent of the
measurement results will meet at room temperature (approximately 25 °C). This
data is not warranted, does not include measurement uncertainty.
Nominal (nom.): indicates the expected mean or average performance, or an
attribute whose performance is by design, such as the 50 ohm connector. This data
is not warranted and is measured at room temperature (approximately 25 °C).
Measured (meas.): describes an attribute measured during the design phase for
purposes of communicating expected performance, such as amplitude drift vs. time.
This data is not warranted and is measured at room temperature (approximately
25 °C).
NOTE: All values represented in this chapter are the measurement results of multiple
instruments at room temperature unless otherwise noted.
