Chapter 2 Front Panel Operations RIGOL
DSG3000 User’s Guide 2-11
Sweep Type
DSG3000 provides two sweep types (“List” and “Step”) and the default is “Step”.
List Sweep
1. Select the list sweep mode
Press SWEEP  Type to select “List”. At this point, the RF signal generator
sweeps according to the current sweep list.
2. Create the sweep list
Press SWEEP and use the page up/down key to open the 2/3 menu page;
then, press List Swp to enter the editing interface of sweep list.
SN Line number. You can add and delete rows using Insert and Delete.
Freq Frequency.
The sweep list can contain up to 6001 frequency points. These
frequency points can locate in any frequency segment within the
maximum frequency range available. You can save sweep lists
applicable to different test settings or frequency ranges and recall
different sweep list when required.
Level Amplitude. It is the corresponding amplitude value of the frequency
point. The sweep list can contain up to 6001 level points.
Time Dwell time. The duration of a sweep step.
 Amplitude Calibration
Press Amp Cal, you can turn on or turn off the measuring sweep list
function with power meter. At this point, you can also record the error
value.
NOTE: The menu is activated when a USB power sensor is connected and
power meter controller (option) is installed, otherwise the menu is grayed
out and disabled.
 Insert
Press Insert to insert a row with the same sweep values below the current
row. At this point, the number of rows of the sweep list increases by one.
 Delete
Press Delete to delete the sweep values of the row currently selected. At
this point, the number of rows of the sweep list reduces by one.
 Goto Row
Press Goto Row to select the desired row for edit in the pop-up menu. It is
