Rosen Aviation 17.5” HD Widescreen Display
Document Number: 102990 Revision: C
Date: 03/17/14
Template: 4.2.3-6-FM; Revision A; 16 May, 2005 Page 14 of 34
7.2.5. Auto Adjust
(RGB only) Use Auto Adjust when the RGB source is active to force the display to
evaluate the RGB signals and ensure that it is interpreting them correctly. To perform an
Auto Adjust within the OSD, select the option and press ENTER. (From the remote, close
the OSD and press the AUTO button.) The screen will go black briefly while the signals
adjust.
7.3. Image Adjust
Use the Image Adjust menu pages, as shown below, to control the color and picture quality.
Highlight Image Adjust and press the
► button to highlight the options, and then press ENTER
to change the option values.
Figure 10 Image Adjust menu pages
7.3.1. Scheme
Scheme is also available from the Main MenuUser page. For information about how
this option works, see Section
7.2.3 on page 13 . Scheme affects changes you make on
the User menu page settings, too.
7.3.2. Brightness
To adjust the picture brightness, press MENU and the
▼ arrow to select Image
AdjustBrightness, and then press ENTER to open the screen below.
Press the ◄ or the ► buttons to change the brightness on the LCD accordingly.
Press ENTER to set the brightness and close the control bar.
Press EXIT to close the OSD.
Figure 11 Image Brightness control bar
