9.1. Troubleshooting
If the display does not function properly, refer to the following troubleshooting table for symptoms
and possible solutions before contacting Rosen field support.
Note: Use an oscilloscope or another display to verify the video signal. Always use a multimeter
to verify voltages. Check actual results against the requirements described in this manual.
Problem Possible Solutions
No video (signal) 
Verify that the display is turned on and the video is on.

Verify that you are in the correct source mode.

Verify that a signal is reaching the display using an oscilloscope or
another display.

Check Power Mode settings on page 24 .

Verify that the pinout is correct.
Screen is black

Verify that the display is receiving power.

Check Power Mode settings on page 24 .

Verify that the pinout is correct.

Verify that the video source is on and DVD installed.

Verify all connections between the source and the display.
Image flashes on/off Perform a Factory Reset from the Technician Menu, on page 22 , to
clear the Auto Detect. See also Momentary Switch Mode on page 26 .
Image flickers 
Verify that the signal cable is secure.

Verify that the vertical frame frequency is 75 HZ or less.
Distorted Image

Verify supported resolution. See Specifications on page 31 .

Verify pinouts.

Verify that a signal is reaching the display using an oscilloscope or
another display.

Examine the display for pinched or damaged cables.
Wrong Colors

If the screen colors are not what you expect, reset the current
scheme. For more information, see
Reset Scheme on page 16 and
Restore Defaults on page 18 .
9.2. Cleaning the Display
To clean the LCD, very gently wipe the screen with a clean, commercially approved LCD
cleaning cloth and alcohol-free LCD cleaning solution. Use one firm cleaning motion instead of
circular or repeated side-to-side scrubbing.
