5. RS-232 AND RS-485 CONTROL INPUTS
Inputs that control the display can come from an IR, RS-232-based 7-button external controller
(P/N 0300-408), or via a cabin management system using RS-232 or RS-485. The 1702 series
displays accept the following commands:
Table 1 RS-485 and RS-232 commands
Control
RS-485 Commands
Power ON
Turn the display on
Power OFF
Turn the display off
Source Composite 1
Select composite 1 video input
Source Composite 2
Select composite 2 video input
Source HD-SDI 1
Select HD-SDI 1 video input
Source HD-SDI 2
Select HD-SDI 2 video input
Source RGB 1
Select analog RGB 1 video input
Source RGB 2
Select analog RGB 2 video input
Source HDMI 1
Select HDMI 1 video input
Source HDMI 2
Select HDMI 2 video input
Source Component 1
Select Component 1 video input (YPbPr 1)
Source Component 2
Select Component 2 video input (YPbPr 2)
Ping Address
(RS-485 only)
Used by master device to detect all devices attached to the
network
Exit
Exit the menu
OK/Enter
Selects active option when OSD is active
Control
RS-232 7-button External Controller Command Set
Power
Toggles the display on or off
Source
Scrolls through enabled video inputs
Menu/Select
Displays OSD
Selects active option when OSD is active
Left
Navigate left through the OSD menu
Right
Navigate right through the OSD menu
Up
Navigate up through the OSD menu
Down
Navigate down through the OSD menu
