Autel Robotics EVO II Dual 640T Enterprise Bundle V3 Drone with Thermal Imaging - Manual (Page 57)

57
6.2 Specifications
Aircraft
Takeoff weight 1150 g
Dimensions (Length x Width x
Height) 230x130x108 mm (folded)
457x558x108 mm (unfolded)
Diagonal length 397 mm
Maximum flight time (no wind) 38 minutes
Maximum hovering time (no wind) 33 minutes
Maximum flight speed
20 m/s (in ludicrous mode)
Maximum ascent speed 8 m/s (in ludicrous mode)
Maximum descent speed 4 m/s (in ludicrous mode)
Maximum flight altitude 7000 meters
Wind resistance 12 m/s (Take-off and landing)
Operating temperature -10 ~ 40ºC
*Operating frequency
902-928 MHz(FCC)
2.400-2.4835 GHz
5.725-5.850 GHz (Countries except for Japan)
5.650-5.755 GHz (Japan)
Transmission power
900M
FCC/ ISED: ≤31 dBm
2.4G
FCC/ ISED: ≤32 dBm
SRRC/CE/MIC/RCM: ≤20 dBm
5.8G (Countries except for Japan); 5.7G
(Japan)
FCC/ISED/SRRC/MIC: ≤33 dBm
CE/ RCM: ≤14 dBm
Hovering accuracy (mild wind or
no wind)
Vertical:±0.1m (when the vision positioning is
active),
±0.5 m (when the GNSS positioning is active);
Horizontal:±0.3m (when the vision positioning
is active),
±1.5 m (when the GNSS positioning is active);
Built-in storage 8G
Supported SD card Max. capacity: 256GB (Class 10 or UHS-3)
Gimbal
Mechanical range
Pitch: -135° to +45°
Heading: -100° to +100°
