Leica CM 1850 – Cryostat
9.
Cleaning, disinfection, maintenance
•
Turn the instrument off with the automatic
mains fuse.
•
Pull the mains plug.
•
Slightly lift the sliding window
(1)
holding it by
the grip
(2)
and pull it out to the front.
•
For the technical specification of the lamp,
please refer to Chapter 4. ‘Technical data‘.
Removal of the lamp
The lamp
(3)
is mounted behind a glare shield
(4)
and therefore not visible.
•
Touch the lamp for better orientation.
•
Lightly
tilt the fluorescent tube down to the left
and pull it out of the clip
(5)
.
•
Hold the lamp with both hands and pull it
to
the left
out of the holder
(6)
.
Installation of the new lamp
•
Hold the lamp in the correct mounting position
as shown
(
Fig. 32
)
and push it to the right until
it engages in the holder.
•
Lightly push the fluorescent tube upward to
engage in the clip.
•
Replace the sliding window.
•
Reconnect the instrument to the mains power
and turn it on.
1
2
3
4
5
6
Fig. 30
Fig. 31
Fig. 32
