6-2
P/N: 4809642
©2004 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
28SEP04(4809642 v1.2)8.1GMTruck
Fig. 6-b
Fig. 6-c
ORIGINAL END CONNECTING TO A/C
COMPRESSOR. SLIGHTLY BENT TO
CURL THE RUBBER SECTION
TOWARD THE FENDER WELL
ORIGINAL END CONNECTING TO A/C PORT
LOCATED NEAR THE FIREWALL, NOW
LOCATED IN THE A/C COMPRESSOR
RUBBER SECTION CURLED
NEAR THE INNER FENDER
