Section 17
CHARGE AIR COOLER HOSE ROUTING
***NOTE***
When routing hoses, refer to Fig. 17-a.
A. Cut a 13.5" length of 3/4" hose. Run this
from the 90° fitting on the Charge Air
Cooler to the straight brass fitting on the
surge tank.
***NOTE***
Make sure to leave the hose slightly long to
allow for engine movement.
B. Cut a 36.5" length of 3/4" hose. Run it from
the bottom fitting on the surge tank along
the fender toward the front and down to the
90° brass fitting on the top of the water
reservoir.
C. Take the supplied 4" x 12" x 90° molded
elbow and cut 1-3/4" from the 4.0" end.
Connect the trimmed end to the straight
brass fitting on the charge air cooler. Route
the long end toward the surge tank. Cut a
110" length of hose and connect it to the end
of the installed molded elbow with the sup-
plied 3/4" union. Route the hose along the
fender well, down toward the water reser-
voir and up under the front bumper. There is
a small opening in the rubber apron between
the bumper and A/C condenser. Pull the
hose up and through, then connect it to the
passenger’s side 90° fitting.
D. Cut a 64" length of 3/4" hose. Run it from
the outlet of the water pump to the same
hose in the rubber apron you pulled the pre-
vious hose through. Pull th hose up and
through, then connect it to the driver’s side
90° fitting.
E. Secure all hose ends with the supplied nylon
clamps.
17.1 CHARGE AIR COOLER HOSE ROUTING
