*** IMPORTANT NOTE ***
Certain model trucks have variances in air conditioning line. Before installing the kit
onto your vehicle, see the following schematic to verify the vehicle has the proper lines.
The Vortech kit is compatible with GM part number 15187285. This line can be
removed from the air conditioning compressor. If your vehicle has GM assembly part
number 15708738 Paxton supercharger system WILL NOT BE COMPATIBLE. This
line assembly is brazed into an aluminum housing and can not be removed. (As shown in
the instructions.)
A/C line and compressor
assembly that is NOT compatible
with the Vortech kit.
(GM 15708738)
A/C LINE AND COMPRESSOR
ASSEMBLY THAT IS COMPATIBLE
WITH VORTECH KIT
(GM 15187285)
DENSO COMPRESSOR
