Parts list – Paxton Superchargers GM 8.1 HD Truck/SUV User Manual
Page 8
viii
P/N: 4809642
©2004 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
28SEP04(4809642 v1.2)8.1GMTruck
Part No.
Description Qty.
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or damaged
parts immediately.
2001, 2003 8.1L GM Truck
Part No. 1101215
PARTS LIST
7P500-026
1/2" NPT - 3/4" HOSE BARB 90°
2
2A017-752-03
SPACER, 750 OD x .927 LONG
2
4PGE010-060
BRKT, BOTTOM HEAT EXCH
1
4PGE010-070
BRKT, TOP HEAT EXCH
1
7A250-075
1/4-20 X 3/4" SHCS PLTD
3
7F250-021
1/4-20 NYLOCK NUTS
5
7J250-001
1/4 SAE WASHERS
10
7A250-151
1/4-20 x 1-1/2" SHCS
2
7C060-035
M6 x 1.0 x 35mm
1
2A017-700
SPACER, .70 L x .75 OD x .351 ID
1
4GPE112-020
DISCHARGE ASSY
1
7R002-048
#48 GOLDSEAL HOSE CLAMP
1
7R002-064
#64 GOLDSEAL HOSE CLAMP
1
7S275-300
2-3/4 x 3 SLEEVE
1
7S300-275
3.00" - 2.75" REDUCER SLEEVE
1
7R002-044
#44 GOLDSEAL HOSE CLAMP
3
4PGE012-020
DISCHARGE TUBE
1
4GL012-030
ELBOW 3.88" - 3.00" x 90°
1
4PGE212-010
AIR INLET ASSY, 8.1 TRK
1
7P156-082
5/32 TEE
1
7R002-016
#16 HOSE CLAMP
4
7R002-056
#56 GOLDSEAL HOSE CLAMP
4
7U030-046
5/32" VACUUM LINE
1.5'
7U034-016
1" GS HOSE
0.416'
7U035-001
3-1/2" FLEX HOSE
1.08'
8D001-001
BYPASS VALVE
1
4PGE112-010
INLET TUBE
1
7P375-625
3/8 NPT x 5/8 HOSE BARB
1
4PGE013-010
ROTO-MOLD AIR BOX
1
7S350-200
3-1/2 x 2" SLEEVE
2
8H040-097
AIR FILTER (K&N) 4" FNG 7" LONG
1
7R002-060
#60 HOSE CLAMP
3
7U133-090
1" ID x 90° MOLDED ELBOW SHORT
1
4HS010-060
FLANGE, AIR BOX
1
7A250-056
1/4-20 x .50" SHCS
6
7J250-022
1/4" WASHER
8
7F250-021
1/4-20 NYLOCK NUT
4
7U133-100
1" I.D. x 90° MOLDED TUBE
1
7P100-010
1" PLASTIC CONNECTING BARB
1
7R002-020
#20 HOSE CLAMPS
3
7R003-024
ADEL CLAMP
1
4PGE010-011
Brkt, Airbox Mounting
2
7E010-075
#12 x 3/4" SHTMETAL SCREWS
2
