Part No.

Description Qty.

Part Number Description Qty.

IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or dam-

aged parts immediately.

2001, 2003 8.1L GM Truck

Part No. 1101215

PARTS LIST

8F060-005

HIGH-FLOW INJECTORS

8

1016120

PAXTON NOVI 1200

1

7U100-070

KEY, 3/16 x 3/16 x 7/8

1

2A040-011

PULLEY, RETAINER S/C

1

7B375-110

3/8 24 x 1" HX

1

7K375-040

3/8 AN960 FLAT WASHR PLATED

1

2A021-081

IMPELLER, MACHINED S-TRIM

1

2H100-032

NAME PLATE, NOVI, UNIVERSAL

1

7A250-037

1/4-20 x 3/8 SHCS PLTD

4

7U100-023

DRIVE SCREW #4 x 1/4

2

2A060-030

MATING RING 10MM .096"

0

2A100-020

RETAINER, COMPRESSOR

1

2H375-024

3/8-24 SPIRALOCK, L.H. 6 PT

1

2H248-008

G/C ASSY, NOVI 1200 CW-POLISH

1

7P375-002

3/8 PIPE PLUG STEEL, ZN PLTD

2

7P375-017

3/8 NPT x 1/2 BEADED HSE BRB

1

7P375-001

OIL FEED FITTING, STD

1

7J375-024

3/8" COPPER WASHER

2

7P375-104

PLUG, OIL HOLE

1

008705

2-3/4" BLUE CAP

1

008701

3.325" PLASTIC CAP

1

008703

1/2" PLASTIC CAP

1

008704

7/16" PLASTIC CAP, BLUE

1

7P125-016

1/8 NPT PLUG

2

2A036-333

S/C PULLEY 3.33" 6-GROOVE

1

7W100-020

O-RING, VOLUTE

1

2A046-112

GATES BELT 112" K061120

1

2A100-030

RETAINER, COMPRESSOR 1/2 SIZE

2

4PGE111-021

ASSY, MTG BRKT 8.1L GM TRUCK

1

4PGE010-044

MTNG PLATE, A LARGE

1

4PGE010-034

MTNG PLATE, B SMALL

1

4PGE017-011

2.231" SPACER

1

4PGE017-021

2.739" SPACER

2

4PGE017-031

2.239" SPACER

3

7A375-124

3/8-16 x 1.25 HXHD

5

7F375-044

3/8 WASHER

14

7A375-375

3/8-16 x 3-3/4" HXHD

3

7F375-016

3/8-16 X NYLOCK NUT

5

7A375-375

3/8-16 x 4.75" HXHD

1

7C010-030

10mm x 1.5 30mm

2

7C010-100

10mm x 1.5 x 100 HxHd XX

3

7J010-002

10mm WASHER

7

7C010-091

10mm x 1.5 x 90 FLAT HEAD

1

7A250-103

1/4-20 x 1" SHCS

2

7A250-022

1/4” WASHER

2

4PGE017-041

SPACER, TENSIONER

1

4FM011-052

SPRING TENSIONER

1

4FA016-171

DUST COVER

1

2A017-033

IDLER, SPACER TENSIONER

1

4FH016-150

IDLER 3" FLANGED

1

4PGE017-051

SPACER, IDLER LONG

1

7C010-045

10mm x 1.5 x 45mm HXHD

1

4FA016-150

IDLER 3.5" FLANGED

1

7A375-350

3/8 - 16 x 3.5" HXHD

1

4PGE139-096

INTAKE MANIFOLD ASSY

1

7P375-006

PCV VALVE FORD

1

7P375-045

3/8 NPT 45° STREET ELBOW

1

7P375-047

3/8 LONG NIPPLE

1

8J040-042

BAFFLE, LT1 VETTE

1

7P375-005

3/8 PIPE PLUGS

2

7P375-039

3/8 NPT - 5/8 BARB x 90°

1

7U033-000

5/8 HOSE

2.3’

7P250-045

1/4 NPT - 3/8 BARB

1

7U032-016

3/8 FUEL HOSE, HIGH PRESS

0.125’

4PGE040-050

GASKET, THROTTLE BODY

1

7R001-008

#8 HOSE CLAMP

2

7P250-120

1/4 PIPE PLUG

1

4PGE130-036

OIL DRAIN ASSY

1

7P375-017

3/8" NPT x 1/2 BARB

1

7U030-036

1/2” OIL DRAIN HOSE

1.83’

7R001-008

#6 HOSE CLAMP

2

7U100-055

TIE WRAPS

4

7T560-001

ROTA-BROACH

1

7T560-002

ARBOR ROTA-BROACH

1

4PGE130-026

OIL FEED ASSY

1

7U030-026

1/4" OIL FEED HOSE

5.16’

7P125-026

FITTING 90° 1/8 NPT x -4

1

7S625-000

HEAT SHIELDING

1.5’

7P375-018

3/8 - 1/8 NPT BUSHING

1

7P125-026

FITTING, 90° 1/8 NPT x -4

1

7P375-033

3/8 NPT x 3/8 NPT STREET ELBOW

1

4GL101-002

FUEL SYSTEM ASSY

1

7P625-030

FTG, GM TRUCK FUEL PUMP

1

7P625-031

FTG, GM TRUCK FILTER

1

7R003-027

ADEL CLAMP, 1-11/16"

2

7U030-050

12mm FUEL HOSE

3.28

7R001-008

#8 STNLS HOSE CLAMP

2

8F001-002

INLINE FUEL PUMP, WALBRO

1

7C010-050

10-24 x 1/2 SHCS

1

7F010-024

10-24 NYLOCK NUT

1

7J010-001

#10 WASHER

2

5W001-014

FUSE HOLDER, 10 GAUGE WIRE

1

SW001-011

16-14 GAUGE EYELET 25" HOLE

1

SW001-025

FEMALE SLIDE, INSULATION, MINI

1

SW001-024

MINI FUSE TAP

1

5W001-015

FUSE, BLADE TYPE 20 AMP

1

5W001-017

3/8" RING TERMINAL 12 GAUGE

1

5W001-042

12 GAUGE 3/16" RING TERMINAL

1

5W001-005

3/8" PLASTIC WIRE LOOM

2

5W001-019

SOLDERLESS CONNECTOR 10-12 GA

1

7U100-044

TIE WRAP 4" NYLON

8

8F101-320

RELAY ASSY, LS1 TRUCK

1

8N201-080

WELDED CORE ASSEMBLY

1

8N101-006

ASSY, CORE INLET, 8.1 GM w/BUNG

1

8N003-070

MANIFOLD COOLER

1

8N101-001

ASSY, CORE w/ENDS

1

8N107-050

WATER PUMP ASSEMBLY

1

8F001-402

PIERBURG, WATER PUMP

1

7R003-027

ADEL CLAMP 1-11/16"

1

5W001-025

FEMALE SLIDE MINI

1

5W001-043

12-10 GA x 1/4" RING TERMINAL

3

7A250-050

1/4-20 x .50" SHCS PLTD

2

5W001-013

14-16 GA BUTT CONNECTORS

4

5W001-019

12-10 GA BUTT CONNECTORS

2

7U100-044

4" TIE WRAPS

4

5W001-022

T-SPLICE CONNECTOR

1

7F250-021

1/4-20 NYLOCK NUTS

1

5W001-015

FUSE, BLADE TYPE 20 AMP

1

5W001-005

3/8" PLASTIC WIRE LOOM

2'

5W001-014

FUSE HOLDER 10 GA WIRE

1

7U100-055

TIE WRAP, 6" NYLON

6

5W001-041

12-10 GA MALE SLIDE INSULATED

2

8F101-320

RELAY ASSY, LS1 TRK

1

8N105-040

WATER TANK ASSEMBLY

1

7U038-000

3/4" HEATER HOSE

19'

7R007-001

NYLON CLAMPS 1-1/8"

12

8N055-030

WATER TANK

1

7P500-026

1/2" - 3/4" HOSE BARB 90°

2

7U100-055

TIE WRAP, 6" NYLON

6

7U038-012

HOSE Ø3/4" 90° 4x12"

1

7U030-065

90° MOLDED ELBOW SHORT

1

7P375-075

3/4" HOSE UNION

1

4GL010-060

WATER TANK MOUNTING BRACKET

1

7A250-050

1/4-20 x .50" SHCS

4

7J250-001

1/4 SAE WASHERS

4

8N056-060

SURGE TANK, PLASTIC

1

8N055-050

SURGE TANK CAP

1

7P500-078

1/2 NPT x 3/4 HOSE FIT

2

4GL010-070

SURGE TANK BRKT

1

8N106-060

WATER COOLER ASSEMBLY

1

8N006-010

WATER COOLER (SETRAB)

1
