Axiom ® User's Guide Version 1.8  May 2015
3. Click [Change] to enter your Windows username and password
4. Click to accept the Windows Login details
Note that your Windows login details are stored separately for each of the printer share, the printing folder share
and the session folder share. You will need to enter your username and password details separately for each,
even if the details are the same for all of them.
Share name entry
The Axiom automatically scans for the available domains, computers and shares. To enter the share name
directly, disable the checkbox, then type the printer or folder share name into the text field.
Test connection
Once you have selected or entered all required details, click the [Test connection] to test the Windows shared
printer or folder. Any detail showing a red X indicates some error or omission which you need to correct before
saving the details.
Windows shared folder example - Missing subfolder
The following table indicates the possible causes of each failure, and the corrective steps.
Failure Cause / Correction
Server The server cannot be found in the specified domain:
Change the server
Change the domain
Login The username and/or password are not authorized for the server:
Change the server
Change the username and/or change the password
Printer The printer cannot be found on the selected server:
Change the printer
Folder The folder or subfolder cannot be found on the selected server:
35
