9.2.3 Scaling function
The scaling function enables parameter setting of the resolution per revolution and
the selected total resolution� It should always be enabled if you want to use the
functions of Class 2 (or the manufacturer-specific classes)�
Octet 9 bit 3
Scaling function
0
Disabled
1
Enabled
9.2.4 Measuring steps per revolution
This parameter is used to assign a requested number of steps referred to one
revolution to the encoder�
If the value of the parameter exceeds the actual physical basic resolution of the
encoder, the output value no longer proceeds by one step�
For encoders as of the B1 generation a parameter fault is displayed in this case;
the device does not change to the cyclic data transfer�
For high-resolution encoders it may be required to split the value into high word
and low word, depending on the projection tool�
Octet
10
11
12
13
Bit
31���24
23���16
15���8
7���0
Data
2
31
to 2
2
4
2
23
to 2
16
2
15
to 2
8
2
7
to 2
0
Requested number of measuring steps per revolution
9.2.5 Total resolution
Octet
14
15
16
17
Bit
31���24
23���16
15���8
7���0
Data
2
31
to 2
2
4
2
23
to 2
16
2
15
to 2
8
2
7
to 2
0
Selected total resolution in measuring steps
This parameter enables the user to adapt the measuring range of the device� The
encoder counts up to the configured total resolution and then it starts again at 0�
Example
Selected: 100 steps per revolution, total resolution 12800, then the encoder starts
again at zero after 128 revolutions and counts again up to 12799�
With many projection tools it may be required to split the value into high word and
low word�
