SPECIFICATIONS AND EXTERNAL DIMENSIONS
CD PLAYER
Audio performance
S/N ratio (1kHz) ...............................................................................................................100dB or more
Dynamic range (1kHz) .....................................................................................................100dB or more
Total harmonic distortion .................................................................................................. 0.01% or less
AUDIO AMP
Rated output (1kHz, total harmonic distortion 0.1%, 8
Ω) ..................................................40W + 40W
Effective maximum output (1kHz, total harmonic distortion 10%, 8
Ω) ..............................50W + 50W
Input sensitivity/impedance
AUX1 ...........................................................................................................................110mV/24k
Ω
AUX2, AUX3 ...............................................................................................................200mV/32k
Ω
Frequency response (5W, 8
Ω)
AUX input ....................................................................................................... 5Hz to 20kHz (
±3dB)
Total harmonic distortion (1kHz, 5W, 8
Ω)
AUX input ...............................................................................................................................0.05%
S/N ratio (10W, 8
Ω, IHF-A)
AUX input ................................................................................................................................. 86dB
TUNER
FM tuner
Range of receivable frequencies ................................................................................87.5 to 108.0MHz
S/N ratio (mono) ............................................................................................................................. 65dB
Sensitivity (S/N 30dB) .......................................................................................................... 6dBµV (IHF)
AM tuner
Range of receivable frequencies ................................................................................... 522 to 1620kHz
S/N ratio ......................................................................................................................................... 45dB
Sensitivity (S/N 20dB) .............................................................................................................55dBµV/m
POWER SUPPLY
Power supply voltage/frequency .....................................................................................AC 230V, 50Hz
Power consumption ........................................................................................................................45W
Power consumption in standby mode ............................................................................... 2.8W or less
Power consumption in low-power mode during standby (display panel off) ..................... 0.6W or less
MISCELLANEOUS
External dimensions (width x height x depth) .........................................................280 x 111 x 302mm
Weight ............................................................................................................................................4.2kg
MISCELLANEOUS
EXTERNAL DIMENSIONS (Units: mm)
300
2
302
111
280
The specifications and external appearance of this unit may be changed without prior notification for the
purpose of improvement.
CLASS 1 LASER PRODUCT
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
