13
Basic
Operations
ENGLISH
Operations possible during playback
Adjusting the master volume
Use VOLUME df to adjust the
volume.
The volume level is displayed.
G Adjustable rangeH
VOLUME 00 – 59, VOLUME MAX
• The variable range differs according to the
input signal.
You can also operate via the main unit. In this
case, perform the following operations.
Press
VOLUME df to adjust the volume.
Turning off the sound temporarily
Press MUTE .
“MUTE ON” is displayed.
To cancel, press MUTE again. Muting can also be canceled by adjusting
the master volume.
Switching the display’s brightness
Press DIMM. .
100 % 70 %
40 % Off
• The display’s brightness switches each
time the button is pressed.
Adjusting the tone
1
Use DBB/TONE to select the tone
parameter to be adjusted.
DBB BASS
TREBLE
2
Adjust the volume with 8
9 or o p .
• To make other tone adjustments at this
time, press DBB/TONE .
• If no operation is performed for 5 seconds,
the adjustment is retained and the normal
display reappears.
DBB Emphasize the bass sound. (Dynamic Bass Boost)
G Selectable modesH ON – OFF
BASS Adjusts the bass sound.
G Variable rangeH –10dB – +10dB
TREBLE Adjusts the treble sound.
G Variable rangeH –10dB – +10dB
Settings made upon purchase:
• DBB .......................................OFF
• BASS ..................................... 0dB
• TREBLE ................................. 0dB
DBB and BASS can be set simultaneously. If the settings were
performed at the same time, the BASS variable range may differ
depending on the volume level.
Listening with headphones
Plug the headphones (sold separately) into the .
• The sound from the speakers is automatically cut off.
NOTE
To prevent hearing loss, do not raise the volume level excessively
when using headphones.
Source direct mode
As the audio signal does not pass through the tone control circuit (DBB/
BASS/TREBLE) in source direct mode, the playback reproduction is
closer to the original sound.
Press S.DIRECT .
• If SOURCE DIRECT on the main unit is pressed, the same function
as with the remote control unit can be obtained.
