2
ENGLISH
Main features
High quality amplifi er stressing sound quality
Equipped with a 70 W + 70 W (6 Ω) high-quality amplifi er circuits.
Direct Play for iPod® and iPhone® via USB
Music data from an iPod can be played back if you connect the
USB cable supplied with the iPod via the USB port of this unit, and
also an iPod can be controlled with the remote control for this unit.
Weight and Dramatic sound
The board and circuit confi guration has been redesigned to achieve
lower impedance. Since stable current is supplied to the power
amp and other sections, it is possible to realize as much as 70
watts of power.
“Simple & Straight” circuit design for sound
purity and free of coloration
This unit gives you high sound quality based on the “simple &
straight” concept. Circuitry is uncomplicated, signal paths are short,
and all adverse infl uences on sound quality have been minimized.
Playback of MP3 and WMA fi les
Supports playback of discs and USB memory devices on which
MP3 or WMA fi les are recorded. The unit’s display can display the
title of the track and the name of the artist of the current track.
Low standby power consumption
Designed with the environment in mind, the unit consumes just
0.5 W while in standby mode.
M-XPort (Marantz-eXtension Port)
This unit is equipped with the M-XPort, a Marantz original innovation
that provides outstanding expandability. You can connect the
Wireless Receiver RX101 (sold separately) to this port.
Cautions on handling
• Before turning the power switch on
Check once again that all connections are correct and that there are
no problems with the connection cables.
• Power is supplied to some of the circuitry even when the unit is
set to the standby mode. When going on vacation or leaving home
for long periods of time, be sure to unplug the power cord from the
power outlet.
• Image persistence (image burn-in)
Do not leave the still images of the disc menu, the unit menu, etc.,
displayed on the TV screen for long periods. This can result in image
persistence (image burn-in) on the screen.
• About Condensation
If this unit is moved from a cold place to a warm place, or installed
in a room subject to rapid temperature rise from a heater, etc.,
condensation (dew) may form on the internal parts of the unit
(operating parts and lenses).
If used in this condition, this unit will not operate correctly and
damage may result. If condensation is formed on the unit, leave this
unit for 1 to 2 hours with the power off before use.
• Cautions on using mobile phones
Using a mobile phone near this unit may result in noise. If that
occurs, move the mobile phone away from this unit when it is in use.
• Moving the unit
Be sure to remove a disc, turn off the power and unplug the power
cord from the power outlet. Next, disconnect the connection cables
to other system equipment before moving the unit.
• About Care
• Wipe the cabinet and control panel clean with a soft cloth.
• Follow the instructions when using a chemical cleaner.
• Benzene, paint thinner or other organic solvents as well as
insecticide may cause material changes and discoloration if brought
into contact with the unit, and should therefore not be used.
• Suffi ciently ventilate the place of installation
If the unit is left in a room full of the smoke from cigarettes, etc., for
long periods of time, the surface of the optical pickup could get dirty,
in which case it will not be able to read the signals properly.
Accessories
Check that the following parts are supplied with the product.
y
e q
t
r
q Remote control unit (RC001ER) .............................................. 1
w R03/AAA batteries ................................................................... 2
e Power cord .............................................................................. 1
r AM loop antenna ..................................................................... 1
t FM indoor antenna .................................................................. 1
y iPod stand ................................................................................ 1
u User guide ............................................................................... 1
About this manual
n Operation buttons
The operations described in this guide are based mainly on remote
control operation.
n Symbols
v
This symbol indicates a reference page on which
related information is described.
This symbol indicates a supplementary information
and tips for operations.
NOTE
This symbol indicates points to remember operations
or function limitations.
n Illustrations
Note that the illustrations in this guide are for explanation purposes
and may differ from the actual unit.
