Revision D
31
June 2011
MAIN MENU:
B:
Set Output Select
SUB-MENU:
c:
HD Dual Link Output
Selects a HD-DL output format type of the selected resolutions:
a:
1080i @ 50
b:
1080i @ 59.94
c:
1080i @ 60
d:
1080p @ 23.97
e:
1080p @ 24
f:
1080p @ 25
g:
1080p @ 29.97
h:
1080p @ 30
i:
1080p @ 50
4:2:2 10b
j:
1080p @ 59.94
4:2:2 10b
k:
1080p @ 60
4:2:2 10b
l:
1080sf @ 23.97
m:
1080sf @ 24
n:
1080sf @ 25
o:
1080sf @ 29.97
p:
1080sf @ 30
1080p50, 1080p59.94, and 180p60 can only be YCbCr 4:2:2 10 bit.
All other resolutions will proceed to a sub-menu for color space and bit width selection.
