Technical Specifications
Frame Rate Formats Supported: Progressive, Interlaced, PsF
Function
Video Standards Supported
Formats
SD-SDI
SMPTE 259M
PAL and NTSC
HD-SDI
SMPTE 292M
All standard HD-SDI compatible formats
Dual-link HD-SDI
SMPTE 372M
All 1080 line video formats compatible with
SMPTE 372M
3G SDI
SMPTE 424M, 425M, Level A and
B
All SMPTE 425 level A and B compatible
formats
Storage Temperature
0 to 50 deg C , 5 – 95 % RH, non condensing
Power Supply Voltage
100 to 240 VAC, 50/60 Hz Universal AC power supply
Power Consumption
26 Watts, typical
Heat Dissipation
88.7 BTUs per hour
Rear Panel Connectors
USB B (1)
Console Port RS-422 M (1)
Console Port RS-232 F (1)
HD-SDI Input BNC Connectors with Loopback outputs (2)
HD-SDI BNC Connectors HD-SDI Out (2)
Genlock BNC Input (1)
RJ45 Connector for 10/100 base ’T’ Ethernet (1)
BNC Connector for GENLOCK input (1)
Operating Temperature and
Humidity
0 to 50 °C (32 to 122 °F); 5 to 95% RH, non-condens ing
Enclosure Dimensions
Rack Size: EIA 19"
Height: 1U-1.72" (43.69mm)
Depth: 9.5 (241.3mm)
Width: 17.49" (444.2mm)
Compliance
Pending approvals for US, Canada, and European Union
