11-14
To do… Use the command… Remarks
Configure optional parameters
See Configuring Optional
Parameters for an NQA Test
Group Optional
The probe count command specifies the number of probe operations during one UDP jitter test. The
probe packet-number command specifies the number of probe packets sent in each UDP jitter probe
operation.
Configuring SNMP Tests
SNMP tests of an NQA test group are used to test the time the NQA client takes to send an SNMP
packet to the SNMP agent and receive a response.
Configuration prerequisites
Before you start SNMP tests, enable the SNMP agent function on the device that serves as an SNMP
agent. For more information abut SNMP agent configuration, see SNMP in the Network Management
and Monitoring Configuration Guide.
Configuring SNMP tests
Follow these steps to configure SNMP tests:
To do… Use the command… Remarks
Enter system view system-view —
Enter NQA test group view
nqa entry admin-name
operation-tag
—
Configure the test type as SNMP
and enter test type view
type snmp Required
Configure the destination address
of SNMP packets
destination ip ip-address
Required
By default, no destination IP
address is configured.
Specify the source port of SNMP
packets
source port port-number
Optional
By default, no source port number
is specified.
Configure the source IP address of
SNMP packets
source ip ip-address
Optional
By default, no source IP address is
specified.
The source IP address must be the
IP address of a local interface. The
local interface must be up;
otherwise, no probe packets can
be sent out.
Configure optional parameters
See Configuring Optional
Parameters for an NQA Test
Group Optional
