STATUS
DE GUARD BAND NOT DOLBY E | DOLBY E,NO V REF | XX ms YY samples CH1&2
...
CH15&16
METADATA INPUT
PROGRAM 1
PROGRAM 8
...
Each item will be placed on the first line and it’s corresponding
status on the second line.
DIALOGUE LEVEL, CHANNEL MODE, LFE CHANNEL,
BITSTREAM MODE, LINE MODE PRO, RF MODE PRO, RF
OVER PROTECT, CENTER DWNMX, SRND DWNMX, DOLBY
SRND, MIXING LEVEL, ROOM TYPE, COPYRIGHT, ORIG
BITSTREAM, EXTENDED BITSTREAM, PREF DWNMX, Lt/Rt C
DWNMX, Lt/Rt S DWNMIX, Lo/Ro C DWNMX, Lo/Ro S DWNMX,
DOLBY SRND EX, HEADPHONE MODE, A/D CONV TYPE, DC
FILTER, LOWPASS FILTER, LFE FILTER, SRND 3dB ATTN,
SRND PH SHIFT
COMMON
NOT ACTIVE | [parameter1 PRESENT | REV parameter1
PRESENT | REV parameter1 ABSENT | REV parameter2 | REV
LAST VALID | REV BLANKED | [USING GEN, [DETECTED
parameter1]]] STATUS
PROGRAM CONFIG, FRAME RATE
Each item will be placed on the first line and it’s corresponding
status on the second line.
parameter1 = EXT | DEC | ABUS
parameter2 = GENERATOR | USER1 | … | USER10 | FACTORY
LOUDNESS
DOLBY LM-100
parameter1 = X dBFS
parameter2 = HR:MN:SC
STATUS
parameter1 parameter2
dBFS OFF | [-60.00, -59.75, …, -0.25, 0]
MEASUREMENT
INTERNAL
STATE, SOURCE, FORMAT, DECODED, TYPE, AES INPUT, RF
INPUT
Each item will be placed on the first line and it’s corresponding
status on the second line.
VAL ELAPSED
AES OUT ALL OK | [MUTE 1L, MUTE 1R, MUTE 2L, MUTE 2R, MUTE 3L,
MUTE 3R, MUTE 4L, MUTE 4R]
DOLBY E ENCODER
DOLBY D ENCODER
FIRMWARE VERSION W.X.Y.Z
STATUS
Each item will be placed on the first line and it’s corresponding
status on the second line.
ENCODING, METADATA STATUS, METADATA SOURCE
Each item will be placed on the first line and it’s corresponding
status on the second line.
FIRMWARE VERSION W.X.Y.Z
STATUS
ENCODING, VIDEO FRAME SYNC, SYNC FRAME RATE,
METADATA STATUS, METADATA SOURCE
