GUIDE TO INSTALLATION AND OPERATION
34 | DAP-1781
4.3.1.3 Dolby Digital sub-tab
The Decoder to Proc Channel Assignment
section indicates the output channel assignment.
The Main Output sub-section shows channels
assignment related to the Program Configuration.
The Dolby Digital Status section indicates status
information for the Dolby Digital bit stream selected
at the bottom of the Control tab: Coding Mode,
Data Rate, Bitstream Mode, Dialnorm value, Dolby
Surround Mode, Surround EX Mode and Preferred
Stereo Downmix.
The Line Mode Profile is used to control the
dynamic range of the outputs.
4.3.1.4 PCM sub-tab
The PCM tab section indicates the output audio
assignment of the Dolby Decoder module when its
input is a PCM signal.
