GUIDE TO INSTALLATION AND OPERATION
DAP-1781 | 65
Appendix B – Default Dolby-E Metadata Parameters
Program Config : 5.1.+ 2
Frame rate : current DAP-1781 frame rate.
Parameter
Program 1 (5.1) Program 2 (2)
Data rate (datarate) not specified not specified
Bitstream mode (bsmod) complete main complete main
Audio coding mode or channel mode (acmod) 3/2 2/0
Center downmix level (cmixlev) -3.0 dB -3.0 dB
Surround downmix level (surmixlev) -3.0 dB -3.0 dB
Dolby Surround mode (dsurmod) not Dolby Surround
encoded not Dolby Surround
encoded
LFE channel (lfeon) enabled disabled
Dialogue level or “dialnorm” (dialnorm) -27 dBFS -27 dBFS
Audio production information (audprodie) disabled disabled
Mixing level (mixlevel) 105 dB SPL 105 dB SPL
Room type (roomtyp) not indicated not indicated
Copyright bit (copyrightb) yes yes
Original bitstream (origbs) yes yes
Extended bitstream information (xbsi1e, xbsi2e) enabled enabled
Preferred stereo downmix mode (dmixmod) Lt/Rt Lt/Rt
Lt/Rt center mix level (ltrtcmixlev) -3.0 dB -3.0 dB
Lt/Rt surround mix level (ltrtsurmixlev) -3.0 dB -3.0 dB
Lo/Ro center mix level (lorocmixlev) -3.0 dB -3.0 dB
Lo/Ro surround mix level (lorosurmixlev) -3.0 dB -3.0 dB
Dolby Surround EX mode (dsurexmod) not Dolby Surround EX
encoded not Dolby Surround EX
encoded
Dolby Headphone mode (dheadphonmod) not indicated not indicated
A/D converter type (adconvtyp) standard standard
DC filter (hpfon) enabled enabled
Lowpass filter (bwlpfon) enabled enabled
LFE lowpass filter (lfelpfon) enabled enabled
Surround phase shift (sur90on) disabled disabled
Surround 3 dB attenuation (suratton) enabled enabled
RF overmodulation protection (rfpremphon) disabled disabled
Line mode compression profile (compr) film standard film standard
RF mode compression profile (dynrng) film standard film standard
