Rugged Cams Rugged Vision DVR - Manual (Page 64)

Image Control
Via Image Control, you can change brightness, contrast, hue, and saturation
settings of the cameras currently displayed.
1. Simply click on + or – to increase or decrease the selected image
control option on the cameras currently displayed.
2. To apply the changes to all cameras, click on the Apply to All button.
3. Click the Restore Defaults button to return settings to the factory
default settings for all cameras.
5. Click on the Close button to exit
the Screen Capture window.
4. To save the captured image,
click on Save and then select the folder to
save to.
3. To print the captured image, click
on Print.
1. To capture an image of the
display screen, click on the Screen Capture
button.
2.
A separate window will open with
a printable form containing the captured
image, time stamp and camera information.
Screen Capture
Forced Recording
To manually start recording, click on the Record button. Click on Record button again to stop
recording.
64
